Product Details
Place of Origin: China
Brand Name: DaLi
Certification: CE
Model Number: DL-1900 cast film extrusion machine/ production line
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: 100000--180000 USD Per Set
Packaging Details: Regular Packing with blanket and stretch film or customized requirment package !
Delivery Time: 2-3 months
Payment Terms: T/T
Supply Ability: 5 sets per month
Name: |
Cast Film Extrusion Machine |
Plastic Processed: |
LLDPE/LDPE/POE/EVA/Elastomer/Polythylene |
Application: |
Sheet/ Film |
Material: |
Granule |
Frequency: |
380V 3P/50HZ, Single Phase 220v, 50hz |
Main Motor Power: |
75KW |
Screw Diameter: |
Φ100 |
Certification: |
CE |
Production Capacity: |
80--100kg/h |
Thickness: |
0.015mm--0.1mm |
Weight: |
10.5T |
Dimension(l*w*h): |
12mx4.5mx3.5m |
Name: |
Cast Film Extrusion Machine |
Plastic Processed: |
LLDPE/LDPE/POE/EVA/Elastomer/Polythylene |
Application: |
Sheet/ Film |
Material: |
Granule |
Frequency: |
380V 3P/50HZ, Single Phase 220v, 50hz |
Main Motor Power: |
75KW |
Screw Diameter: |
Φ100 |
Certification: |
CE |
Production Capacity: |
80--100kg/h |
Thickness: |
0.015mm--0.1mm |
Weight: |
10.5T |
Dimension(l*w*h): |
12mx4.5mx3.5m |
High precision.automatic or manual T-die head, with film thickness automatic detect instrument. with the positive pressure and negative pressure device;on-line marginal film recycling machine will greatly reduce production cost, auto metering counting, automtaic cutting and auto change winding roller. PLC control the winding unit .
Material |
CPE/TPE |
Working width |
1600mm max |
Thickness range |
0.015mm to 0.1mm |
Screw Dia. and L/D |
Φ100×35:1 X 1 |
T die width | 2100mm |
Roller surface length | 2100mm |
Winding Diameter | Φ500 |
Power supply | Three Phase 380V( ±10% )50hz, Single Phase 220V 50Hz |
Mechanical speed: | 30-100m/min |
Extrusion capacity(Maximum) | 100~150kg/h(varies with material) |
Installation power |
About 160kw ( actual consumption is 40%-50% of total installation power) |
Installation space |
L=12M; W=4.5m; H=3.5m
|
Scene of assmebly workshop
